Helical Shaft Mounted Speed Reducer Metal Shredder Electric Power Motor

  • img.alt
  • img.alt
  • img.alt
Place of Origin Wenzhou City,Zhejiang,China
Brand Name HENGTAI
Certification CE,ISO9001:2008,ISO14001,GB28001
Model Number HH series
Minimum Order Quantity 5 PIECES
Price USD1000-100000
Packaging Details 1 PCS PACKED IN ONE SMALL BOX, 7- 8 SMALL BOXES PACKED IN ONE WOODEN CRATE
Delivery Time 40 days
Payment Terms T/T or LC
Supply Ability 100 PCS PER MONTH
Product Details
High Light

helical speed reducer

,

inline helical gearbox
Leave a Message
Product Description



Helical Shaft Mounted Speed Reducer Metal Shredder Electric Power Motor





Quick Details



·         Gearing Arrangement: Helical



·         Output Torque: 450000 N.m



·         Rated Power: 1.1-5100KW



·         Input Speed: 750-1500 rpm



·         Output Speed: 1.67-1200RPM



·         Place of Origin: Zhejiang, China (Mainland)



·         Model Number: H1SH3-H4SH26



·         Brand Name: HENGTAI



·         Color: According to customer



·         Ratio: 1.25-450



·         Mounting position: foot mounted



·         Material for box: cast iron



·         Packing: Strong wooden cases for exporting



·         Output shaft: Solid or hollow output shaft



·         Accessories: cooling system, lubrication system



·         Output shaft diameter: 30-420MM





Descriptions:



Type

Stage

Model

Ratio

Nominal Power (KW)

Nominal Torque(N.m)

Shaft

Mounting

B Series Bevel-helical Gear Unit

Double-stage

4--18

5--14

41-4,436

5,800-226,000

S. Solid Shaft                                   H. Hollow Shaft                                 D.Hollow Shaft for Shrink Disk

H:Horizontal   V:Vertical M:Horizontal Design Without Feet

Three-Stage

4--26

12.5-90

62-4,452

70,100-952,000

Four-Stage

5--26

80-400

2.6-1,652

10.6-945,000



Your benefits:



1. Extremely robust gear unit housing



2. Reduced costs and weight due to high power density and finely stepped sizes



3. Effective cooling systems



4. CCW and CW versions may be implemented in a single gear unit version



5. Flexible mounting capability



6. Efficient project planning tools including 2D and 3D dimension drawing generators



7. Short delivery times for standard versions and spare parts





Specification:



Series

Transmission Ratio  (i)

models

H1

1.25-5.6

H1SH3, H1SH5, H1SH7, H1SH9, H1SH11, H1SH13, H1SH15, H1SH17, H1SH19

H2

6.3-28

H2SH4, H2SH5, H2SH6, H2SH7, H2SH8, H2SH9, H2SH10, H2SH11, H2SH12, H2SH13, H2SH14, H2SH15,



H2SH16, H2SH17, H2SH18, H2SH19, H2SH20, H2SH21, H2SH22, H2SH23, H2SH24, H2SH25, H2SH26



H3

25-112

H3SH4, H3SH5, H3SH6, H3SH7, H3SH8, H3SH9, H3SH10, H3SH11, H3SH12, H3SH13, H3SH14, H3SH15,



H3SH16, H3SH17, H3SH18, H3SH19, H3SH20, H3SH21, H3SH22, H3SH23, H3SH24, H3SH25, H3SH26



H4

100-450

H4SH5, H4SH6, H4SH7, H4SH8, H4SH9, H4SH10, H4SH11, H4SH12, H4SH13, H4SH14, H4SH15, H4SH16,



H4SH17, H4SH18, H34H19, H4SH20, H4SH21, H4SH22, H4SH23, H4SH24, H4SH25, H4SH26







Applications:



Bucket elevator drives



Separator drives



Water screw drives



Conveyor drives



Dryer section drives







The cause for breakdown and settlement of reducer:



Breakdown

Possible cause

The way of settlement

The motor does not run in case of loading

Voltage is too low

Check to see if the wire is too long or too thin

Gear is damaged

Repair it in special factory

Work with overload

Discharge load

Very hot

Work with overload

Discharge load

Start and stop too many

Discharge load

Bearing is damaged

Reduce using frequency

Voltage is too high or too low

Repair or replace

Loud noise

If the noise is loud and continuous, the bearing is damaged or the gear damaged

Repair it in special factory

If the noise is loud occasionally, the gear must be damaged or something else block

Contact with the service institution

















Warranty:



HFT guarantees the products sold for one year from the date of delivery. Warranty is limited to repair or



replacement, free at our plant, of defective parts due to an ascertained defect of material or manufacture.



The parts replaced remain our property. All other compensation is excluded, nor can any direct and/or



indirect damage be claimed of any nature, also for the temporary lack of use of the goods purchased.



Helical Shaft Mounted Speed Reducer Metal Shredder Electric Power Motor 0





Helical Shaft Mounted Speed Reducer Metal Shredder Electric Power Motor 1
