HXG Series Helical Worm Gearbox Hollow Shaft With Hardened Gear

  • img.alt
  • img.alt
Place of Origin Wenzhou City,Zhejiang,China
Brand Name HT
Certification CE,ISO9001:2008,ISO14001,GB28001
Model Number HXG series
Minimum Order Quantity 5 PIECES
Price USD200-2500
Packaging Details 1 PCS PACKED IN ONE SMALL BOX, 7- 8 SMALL BOXES PACKED IN ONE WOODEN CRATE
Delivery Time 20 Days
Payment Terms T/T or LC
Supply Ability 1000 PCS PER MONTH
Product Details
High Light

helical speed reducer

,

helical bevel gearbox
Leave a Message
Product Description

HXG Series Helical Worm Gearbox Hollow Shaft With Hardened Gear





Quick Details:



·                                 Output shaft diameter: 35-135MM



·                                 Output Torque: 180Nm-17000 N.m



·                                 Rated Power: 0.92-226 KW



·                                 Input Speed:500-1400 rpm



·                                 Output Speed: 15.1-280RPM



·                                 Place of Origin: Zhejiang, China (Mainland)



·                                 Model Number: HXG30-HXG125



·                                 Brand Name: HENGTAI



·                                 Ratio: 5-31



·                                 Mounting position: Shaft mounted



·                                 Material for box: cast iron



·                                 Packing: Strong wooden cases for exporting



·                                 Output shaft: Hollow output shaft



·                                 Accessories: Backstop, Torque arm, etc



·                                 Gearing Arrangement: Helical





Descriptions:



HXG series shaft mounted speed reducer with hardened gears have large carrying capacity,smooth



transmission,light weight,low energy consumption and so on characteristics,input shaft of reducer is



connected with motor by belt pulley,output hollow shaft linked with a key.





Specifications:





Model Number



Input shaft Diameter

Output shaft hollow bore diameters:



Output torque

range

Torque arm length

Input Speed

Reduction Ratio:



Ta35-35D



19mm

30mm



1000Nm

220mm











1400rpm





900rpm





500rpm



5:1



7:1



10:1



12.5:1



15:1



20:1



25:1



31:1



Ta40-40D



24mm

40mm



1350Nm

240mm

Ta45-45D



28mm

45mm



2050Nm

260mm

Ta50-50D



42mm

50mm



2100Nm

280mm

Ta60-60D



48mm

60mm



3500Nm

300mm

Ta70-70D



48mm

70mm



4900Nm

320mm

Ta80-80D



55mm

80mm



6600Nm

380mm

Ta100-100D



55mm

100mm



10500Nm

520mm

Ta124-125D



60mm

125mm



16000Nm

560mm







WARRANTY:



HFT guarantees the products sold for one year from the date of delivery.



Warranty is limited to repair or replacement, free at our plant, of defective parts due to an ascertained



defect of material or manufacture. The parts replaced remain our property. All other compensation is



excluded, nor can any direct and/or indirect damage be claimed of any nature, also for the temporary lack



of use of the goods purchased.





Spare parts list:

TA Helical parallel shaft mounted gear motor Spare Parts List



1.Casing



11.Bearing



21.Hex.head screw



31.Spacer ring



41.Pin for bracket



2.Cover



12.Bearing



22.Spring washer



32.Spacer ring





42.Pin for support



3.Rubber cap



13.Bearing



23.Hexagonal nut



33.Support



43.Cotter pin



4.Output shaft



14.Oilseal



24.Hexagonal head screw



34.Key





5.Gearwheel



15.Oilseal



25.Breather plug



35.Support





6.Input shaft



16.Rubber cap



26.Level plug



36.Bracket





7.Spacer ring



17.Circlip



27.Drain plug



37.Torque arm





8.Spring washer



18.Key



28.Rubber Cap



38.Right tie-rod





9.Gasket



19.Key



29.Spacer ring



39.Left tie-rod





10.Gasket



20.Dowel Pin



30.Clutch element



40.Hexagonal nut











Applications:



Mechanical transmission fields



Stone Crushing Plant Equipments :

  • Vibrating Screen
  • Primary Crusher
  • Secondary Crusher
  • Belt Conveyors
  • Control Units
  • Drive Motor



Product images:



HXG Series Helical Worm Gearbox Hollow Shaft With Hardened Gear 0



HXG Series Helical Worm Gearbox Hollow Shaft With Hardened Gear 1
