Planetary Solid Liquid Separation
| Place of Origin | Wenzhou city, Zhejiang, China |
|---|---|
| Brand Name | HENGTAI |
| Certification | CE; ISO9001:2008; ISO 14001 GB 2800 |
| Model Number | CQW series |
| Minimum Order Quantity | One piece |
| Price | It depends on your quantity |
| Packaging Details | Strong exporting wooden case and pallets |
| Delivery Time | It depends on the models of your requirements |
| Payment Terms | L/c, T/T, Western union |
| Supply Ability | It depends on the models of your requirements |
Product Details
| High Light | liquid solid separation equipment,solid liquid separator |
||
|---|---|---|---|
Product Description
Quick Detail:
Gearing Arrangement: Planetary
Allowable torque: 12000~400000 Nm
Power range: 2.2~4 KW
Input Speed: 500-1800 rpm
Output speed: 1~ 0.3 rpm
Place of Origin: Zhejiang, China
Lifting distance: 150~500 mm
Mounting position: foot/vertical flange mounted
Model Number: CQW
Brand Name: HENGTAI
Color: According to customer
Other name:
CQW series settling tank
CQW series points settling tank which are widely used in alumina industry
CQW series points settling tank which are widely used in alumina industry for red mud settlement
Description:
Solid-Liquid Separation is a major unit operation that exists in almost every flow scheme related to the
chemical process industries, ore beneficiation, pharmaceutics, food or water and waste treatment.
Have been researching for almost 23 years, it is obviously that me made a great progress in these area.
Points settlement tank is just the latest product which is pioneer in domestic.
Points settlement tank, compared with ordinary settlement tank, has a simple process, flow of soil layers
high at the end, scarring less and fluid containing high in the bottom, overflow plankton less, high
productivity per unit area, covers less area and hydrolytic loss low etc.
Applications:
Thickeners are used for dewatering slurries of either tailings or product. A thickener is a large circular tank
that is used to settle out the solid material from the water in the feed slurry. It is widely used for dealing
with slime, wastewater, waste residue in metallurgy, mine, coal, petrochemical industry, building materials,
environmental protection department etc.
Specifications:
Lets us pick a topic, red mud settlement of alumina industry, as an example.
|
Model |
Quantity of settlement (t/h) |
Output rotate speed(r/min) |
Maximum torque (n·m) |
Weight(kg) |
|
GLDS 7 |
6~12 |
1~0.1 |
200000 |
19600 |
|
GLDS 10 |
20~28 |
1~0.1 |
250000 |
28650 |
|
GLDS 14 |
32~40 |
1~0.1 |
300000 |
38900 |
|
GLDS 16 |
60~80 |
1~0.1 |
400000 |
39800 |
|
GLDS 18 |
90~100 |
1~0.1 |
500000 |
43250 |
|
GLDS 20 |
110~130 |
1~0.1 |
680000 |
49800 |
Performance Feature:
1. CQW series have multiple drive unit, CQW type Drive through the base plate installed on the central
pillar head, the driving mechanism comprises a worm gear box, one B3 type reducer drive. Special
structural design can be directly combined elevator, the hollow output shaft with double guide groove,
ensure flexible lifting elevator.
2. PLC module can realize multiple automatic control mode.
3. 3 series can realize 8KN.m, 16KN.m, 30KN.m output, suitable for use in the small settlement which
trough mud layer is not high.
4. The data of driving mechanism are below:
Continuous rated torque 100 % (KN.m):10-40
Output speed (RPM):1-0.3
Output power (KW):2.2-4
Elevator input power(KW):2.2-3
Competitive Advantage:
1. The tank is high-efficiency and has been identified by NSTC.
2. Compared with the common one, there are the advantages as following:
Scarring less
Simple process
Overflow plankton less,
Flow of soil layers high at the end
Fluid containing high in the bottom, etc.
