Industrial Planetary Gearbox Gear Reducer
| Certification | CE,ISO9001:2008,ISO14001,GB28001 |
|---|---|
| Model Number | HP series |
| Minimum Order Quantity | 1 PIECES |
| Price | USD3300.00-USD90000.00 |
| Packaging Details | 1 PCS PACKED IN ONE SMALL BOX, 1 BOXES PACKED IN ONE WOODEN CRATE |
| Delivery Time | DEPENDS ON QUANTITY |
| Payment Terms | T/T or LC |
| Supply Ability | 500 PCS PER MONTH |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Highlight | Low Backlash Planetary Gearbox,helical planetary gearbox |
||
|---|---|---|---|
Product Description
Planetary Gear Unit with Primary Bevel-Helical Gear Stage P2K
Quick Details:
Models:
P2S, P3N, P3S, P2K, P2L, P3K.
B=Solid shaft with parallel key or involute splines
A:=hollow shaft with shrink disk or involute splines
K=bevel-helical gear stage
L=bevel gear stage
S=helical gear stage
Power range:0.4∼ 9551 KW
Ratio rang: I = 3.5∼15000
Torque rang: 450∼11205000 N.m
Input Speed: 750rpm – 1800 rpm
Output Speed: 0.1 rpm- 350 rpm
Mounting position: foot mounted, hollow shaft mounted, solid shaft mounted
Output shaft: hollow shaft , solid shaft
Gearcase housing: HT cast Iron Housing suitable for outdoor installation
Backstop: Available on all frame sizes With/without anti-back Backstop
Applications:
Extruders
Dough mills
Rubber calenders
Cooling drums
Agitators
Metal working mills
Roller tables
Specifications:
Model: P2NA, P2LA, P2SA, P2KA
Sizes:9,10,11,12,13,14,16,17,18,19,20
Model | P2NA | ||||||||||
9 | 10 | 11 | 12 | 13 | 14 | 16 | 17 | 18 | 19 | 20 | |
Output Torque(Nm) | 22000 | 31000 | 42000 | 60000 | 83000 | 117000 | 160000 | 202000 | 244000 | 295000 | 354000 |
Competitive Advantage:
1.Raw material from original steel rolling factory.
2.Strict controll on gear processing heat treatment.
3. 18 months quality guarantee.
