Awl Chemical Mixers Agitators Side Entry with Gelisen arc-making gear
| Place of Origin | Wenzhou City,Zhejiang,China |
|---|---|
| Brand Name | Hengtai |
| Certification | CE,ISO9001:2008,ISO14001,GB28001 |
| Model Number | FL series |
| Minimum Order Quantity | ONE PIECE |
| Price | DEPENDS ON REQUIREMENTS |
| Packaging Details | 1PC PACKED STRONG EXPORTING WOODEN CASE WITH PALLETS |
| Delivery Time | 25-35 days |
| Payment Terms | T/T or LC |
| Supply Ability | DEPENDS ON THE SPECIFIC MODEL |
Product Details
| High Light | tank mixers agitators,industrial agitators mixers |
||
|---|---|---|---|
Product Description
Awl Chemical Mixers Agitators Side Entry with Gelisen arc-making gear
Quick Details:
|
Gearing Arrangement |
Awl |
|
Output Torque |
65~650N.m |
|
Rated Power |
0.55~22KW |
|
Input Speed |
Accordingly |
|
Output Speed |
240~550RPM |
|
Place of Origin |
Zhejiang, China (Mainland) |
|
Model Number |
FL series |
|
Brand Name |
HENGTAI |
|
Color |
According to customer |
|
Ratio |
2.73~4.09 |
|
Mounting position |
Vertical or leaning mounted |
|
Material for box |
Cast Iron |
|
Packing |
Standard Fumigation Wooden |
Descriptions:
FL series Side Entry Agitator reducer is used gelisen arc-making gear to transmit.The material of gear is
chosen and usd high-intension alloy steel whose quenching rigidlity is HRC 59-62.The machine is with
shutoff equipment when urgentlyand when the mechanical airproof need repairing or changing,no need to
empty the left liquid,only pull out mixer shaft for some distance to make the block head enter into the
airproof seat,then turn the shaft,the block head and airproof seat will be fastened to keep the liquid out of
the outside.
Other name:
Side enter agitator reducer
Awl gear reducer applied for agitating industry
Coned gear box with more transmission efficiency
Warranty:
HFT guarantees the products sold for one year from the date of delivery.
Warranty is limited to repair or replacement, free at our plant, of defective parts due to an ascertained
defect of material or manufacture. The parts replaced remain our property. All other compensation is
excluded, nor can any direct and/or indirect damage be claimed of any nature, also for the temporary lack
of use of the goods purchased.
Your benefit:
1. Strong carring,Long life
2. Small volume and Light Weight
3. Small Power,High Rotating Speed and Efficiency.
4. Save Electric energy of 30-50% if large-scale milled kettle in the condition of the same milled
effect.
Applications:
Mainly applied for Chemical Industry and Machinery for Food Industry.
Specifications:
|
Type |
Outview axis diameter |
Puddler |
Weight(kg) |
|
FL40 |
φ40 |
TX250-TX400 |
<125 |
|
FL55 |
φ55 |
TX400-TX550 |
<370 |
|
FL65 |
φ65 |
TX500-TX700 |
<710 |
THE CAUSE FOR BREAKDOWN AND SETTLEMENT OF REDUCER
|
Breakdown |
Possible cause |
The way of settlement |
|
The motor does not run in case of loading |
Voltage is too low |
Check to see if the wire is too long or too thin |
|
Gear is damaged |
Repair it in special factory |
|
|
Work with overload |
Discharge load |
|
|
Very hot |
Work with overload |
Discharge load |
|
Start and stop too many |
Discharge load |
|
|
Bearing is damaged |
Reduce using frequency |
|
|
Voltage is too high or too low |
Repair or replace |
|
|
Loud noise |
If the noise is loud and continuous, the bearing is damaged or the gear damaged |
Repair it in special factory |
|
If the noise is loud occasionally, the gear must be damaged or something else block |
Contact with the service institution |
Competitive Advantage:
1. HFT total registered capital in RMB 58,000,000.We had 2 sub companies located in Binghai& Sanxi Industry Zone, covering area 50000 square meters and 350 staff so far.
2. As the leader in gear reducer domestically, we are committed to R&D all the time. There are more than 40 professional technical engineers. We had 49 items patents including 7 items of invention
patent, 30 items of utility models, 1 item of appearance design, 2 items of international invention patent and 5 items which are accepted by National SIPO wait for approval.
3. According to the globalization strategy, we have established pre-sale,after-sale and whole-process selling network. Relying on high quality products and perfect service, our products have been successfully applied by more than 5000 customers.
