High Precision Cycloidal Speed Reducer Dual Drive With High Torque
| Place of Origin | Wenzhou City,Zhejiang,China |
|---|---|
| Brand Name | HENGTAI |
| Certification | CE,ISO9001:2008,ISO14001,GB28001 |
| Model Number | HJX series |
| Minimum Order Quantity | FIVE PIECES |
| Price | PLS REFER TO PRICE TABLE |
| Packaging Details | 1 PCS PACKED IN ONE SMALL BOX, 7- 8 SMALL BOXES PACKED IN ONE WOODEN CRATE |
| Delivery Time | DEPENDS ON QUANTITY |
| Payment Terms | T/T or LC |
| Supply Ability | TWO THOUSAND PCS PER MONTH |
Product Details
| High Light | helical speed reducer,inline helical gearbox |
||
|---|---|---|---|
Product Description
High Precision Helical Gear Reducer Dual Drive With High Torque
Quick Details
Gearing Arrangement: Dual drive transmission device
Ratio: up to 49295
Nominal output torque up to 40000Nm
Max output torque up to 100000Nm
Static load 120 KN
Dynamic Load 75KN
Place of Origin: Zhejiang, China (Mainland)
Brand Name: HENGTAI
Color: According to customer
Packing: Strong wooden cases for exporting
Description:
HJX Helical Gear Reducer of parabolic trough tracking is high-precision drive, low backlash ,the inaccuracy is limited to less than 1 arc
centimeter, no gap for the output shaft, which composed by the horizontal ,pitching drive mechanism parts.
Besides, HJX Helical Gear Reducer of parabolic trough tracking has great loading capacity which adopts 4 to 5 times transmission capacity
of high loading and resisting to shock than worm drive under the same conditions.
Combined with high-precision gears and precision rolling gears, transmission ratio of HJX Helical Gear Reducer of
parabolic trough tracking is about 50,000,the overall efficiency is higher than 68%.
Your benefits:
1. HJX combination of precision gear reducer and bicyclic cycloid reducer mechanism. Achieve accurate tracking pitch direction 360 °positioning.
2. Purely mechanical drive performance and stability for easy maintenance
3. High-precision transmission, large output stiffness, low retrace tolerance
4. With long life grease, no need to replace the lubricant;
Specification:
Ratio: up to 49295
Nominal output torque up to 40000Nm
Max output torque up to 100000Nm
Static load 120 KN
Dynamic Load 75KN
Applications:
Widely applied for energy, military industry, aerospace, industrial automation and other transmission
equipment industries, especially for solar thermal power generation and tracking system of heliostat, the
sun tracking system of photovoltaic panels, radar tracking system etc.
The cause for breakdown and settlement of reducer:
|
Breakdown |
Possible cause |
The way of settlement |
|
The motor does not run in case of loading |
Voltage is too low |
Check to see if the wire is too long or too thin |
|
Gear is damaged |
Repair it in special factory |
|
|
Work with overload |
Discharge load |
|
|
Very hot |
Work with overload |
Discharge load |
|
Start and stop too many |
Discharge load |
|
|
Bearing is damaged |
Reduce using frequency |
|
|
Voltage is too high or too low |
Repair or replace |
|
|
Loud noise |
If the noise is loud and continuous, the bearing is damaged or the gear damaged |
Repair it in special factory |
|
If the noise is loud occasionally, the gear must be damaged or something else block |
Contact with the service institution |
Storage:
1: Pls do not store in outdoor.
2: Pls put cardboard, wood or other material between the products and floor. the gear box cannot directly
touch the floor.
Warranty:
HFT guarantees the products sold for one year from the date of delivery. Warranty is limited to repair or
replacement, free at our plant, of defective parts due to an ascertained defect of material or manufacture.
The parts replaced remain our property. All other compensation is excluded, nor can any direct and/or
indirect damage be claimed of any nature, also for the temporary lack of use of the goods purchased.
