Parallel Shaft Helical Gearbox / Vertical to Horizontal Gearbox

  • img.alt
Place of Origin Wenzhou City,Zhejiang,China
Brand Name Hengtai
Certification CE,ISO9001:2008,ISO14001,GB28001
Model Number HS series
Minimum Order Quantity 5 PIECES
Price USD122-1648
Packaging Details 1pcs packed in one small box, 7-8 small boxes packed in one wooden crate
Delivery Time 25-35 days
Payment Terms T/T or LC
Supply Ability 2000pcs/month
Product Details
High Light

helical speed reducer

,

inline helical gearbox
Leave a Message
Product Description

Parallel Shaft Helical Gearbox / Vertical to Horizontal Gearbox





Quick Details:





·                                 Gearing Arrangement: Helical



·                                 Output Torque:78~3400N.m



·                                 Rated Power:0.12~75KW



·                                 Input Speed: Accordingly



·                                 Output Speed: 2.28~199RPM



·                                 Place of Origin: Zhejiang, China (Mainland)



·                                 Model Number:HS series



·                                 Brand Name: HENGTAI



·                                 Color: According to customer



·                                 Ratio: 7~291.4



·                                 Mounting position: flange mounted or foot mounted



·                                 Material for box: Cast Iron



.                                 Packing: Standard Fumigation Wooden







Descriptions:



Worm gearbox HS series same as SEW S series can be used in every industrial sector and tailored to



individual torque and speed requirements due to their outstanding efficiency.







Specification:



                  Model

37

47

57

67

77

87

97

Structure

S,SA,SF,SAF,SAZ,SAT

Input Power KW

0.12~75

0.12~1.5

0.12~3

0.12~3

0.25~7.5

0.55~18.5

0.75~22

Transmission Ratio   i

7~157.3

7.33~198.8

7.33~198.8

8.75~210

8.17~265.7

7.83~291.4

8.12~288.7

Allowed Torque  Nm

78

145

250

450

1080

1940

3400

Weight   kgs

8

11

15.5

29

55

110

190





Note:



SA:   hollow shaft output



SF:   flange-mounted output



SAF:  flange-mounted hollow shaft output



SAZ:  short-flange-mounted hollow shaft output



SAT:  torque-arm-mounted hollow shaft output







Your benefits:



1.     Economical operation



2.     Low noise



3.     Long service life



4.     High permitted overhung loads











Applications:



Widely applied for the Building machinery,Chemical industry,Conveyor machinery,Metal cutting machine



and Metal rolling machine etc.







THE CAUSE FOR BREAKDOWN AND SETTLEMENT OF REDUCER



Breakdown

Possible cause

The way of settlement

The motor does not run in case of loading

Voltage is too low

Check to see if the wire is too long or too thin

Gear is damaged

Repair it in special factory

Work with overload

Discharge load

Very hot

Work with overload

Discharge load

Start and stop too many

Discharge load

Bearing is damaged

Reduce using frequency

Voltage is too high or too low

Repair or replace

Loud noise

If the noise is loud and continuous,the bearing is damaged or the gear damaged

Repair it in special factory

If the noise is loud occasionally,the gear must be damaged or something else block

Contact with the service institution







Warranty:



HFT guarantees the products sold for one year from the date of delivery.



Warranty is limited to repair or replacement, free at our plant, of defective parts due to an ascertained



defect of material or manufacture. The parts replaced remain our property. All other compensation is



excluded, nor can any direct and/or indirect damage be claimed of any nature, also for the temporary lack



of use of the goods purchased.







Competitive Advantage:



      1.  HFT total registered capital in RMB 58,000,000.We had 2 sub companies located in Binghai& Sanxi



      Industry Zone, covering area 50000 square meters and 350 staff so far.



2.  As the leader in gear reducer domestically, we are committed to R&D all the time. There are more



than 40 professional technical engineers. We had 49 items patents including 7 items of invention



patent, 30 items of utility models, 1 item of appearance design, 2 items of international invention patent



and 5 items which are accepted by National SIPO wait for approval.



3.  According to the globalization strategy, we have established pre-sale,after-sale and whole-process



selling network. Relying on high quality products and perfect service, our products have been



successfully applied by more than 5000 customers.





Parallel Shaft Helical Gearbox / Vertical to Horizontal Gearbox 0

Parallel Shaft Helical Gearbox / Vertical to Horizontal Gearbox 1
